Fit two Dzus fasteners at the bottom of the front end, And one at The Top. Mount Dzus plates behind them to the car.

Front End Mounting Kit .Price=295.00

(This Price Does Not Include Shipping if ordered seperately, But If ordered With fiberglass parts we can include it into the boxes so shipping would then be included .)

Made From lightweight Chromoly Tubing



Front End Mounting Kit Includes:

....

Tip: Tack weld the kit together inside of the front end,

then remove it to finish welding it outside of the front end.



Instructions:

Click On The Thumbnails Below For Installation Photo's







A. 4" x 4" Plates get temporarily riveted to the sides of the fenders, the lower pan and the upper pan.

B. Fit Long tube "B" and end tubes "C" for length, then weld plates on the end tubes"C".

Next weld the end tubes"C" to the long tube"B"

C. Weld Slip tube "E" to the cars front frame rails.

D. Tack weld the kit together inside of the front end, At The End Of The Install, Use The "C"
Clip and Tack Weld it
To The Center Tube, Right next To The Frame Rail Plates and This Creates A stop That Doesnt Allow The Front End To Slide Side To Side.


E. Fiberglass over "A" plates to hold it in the front end. Or rivet them in place.

F. Set up Dzus Plates and Buttons



Front End Tilt Mounting Kit .Price=310.00

(This Price Does Not Include Shipping if ordered seperately, But If ordered With fiberglass parts we can include it into the boxes so shipping would then be included .)

Made From lightweight Chromoly Tubing

Same as Front end mounting kit, But Has additional plates that bolt to the acceptor plates so the

Front End Can Pivot

....






Door Hinge Kits. Price=$200.00 for the set Shipping and Handling $35.00 = $235.00

(Does NOT Work on 1937'- 55'- 56'- 57' Chevy's)

(This Price Does Not Include Shipping if ordered seperately, But If ordered With fiberglass parts we can include it into the boxes so shipping would then be included .)

The most precise door hinge available! Our kit features 4 door mounting pads for customized mounting locations,as well as 4 Backing plates

Allow's a more accurate door alignment and easier door removal.

Just open the door and lift off!

Made From lightweight Chromoly Tubing




Miscellaneous Items for Sale.

(The Prices Do Not Include Shipping if ordered seperately, But If ordered With fiberglass parts we can include it into the boxes so shipping would then be included .)


Aluminum Hood Springs . Best For average sized hoods (Such as 68-72 Nova, 70-81 Camaro and 70-72 Chevelle.) Price= $45.00 + Shipping and Handling Price-$25.00, total=$65.00 a pair Weight=3 a pair. Ship: UPS Item.

Springs 7" total length to tight stretch - Don't hold hood up, use a prop rod or drill hole in hinge-use cotter pin.





Brass Hood Springs . For longer and Heavier hoods (Such as 70' 442, 70-72 Monte Carlo, and 71-74 Charger power bulge.) Price= $45.00 + Shipping and Handling Price-$25.00, total=$65.00 a pair Weight=3 a pair. Ship: UPS Item.

Springs 7" total length to tight stretch - Don't hold hood up, use a prop rod or drill hole in hinge-use cotter pin.



Package of 10 Aluminum DZUS Fasteners and Steel Backing Plates. Price=$50.00 For a Set of Ten. Shipping and Handling Price $20.00 = $70.00 Weight=3. Ship: UPS Item.

Oval 5/8" thickness regular length (10 exterior Stainless Steel color.)





Lanyard hood Pins and Backing Plates. Price=$30.00 Shipping and Handling Price $20.00 = $50.00 For a Pair. Weight=1. Ship: UPS Item.





Scoop Plugs. Price $25.00 Shipping and Handling Price $20.00 = $45.00 Weight=1 Ship: UPS Item.



4 Small Dummy Headlights 5-1/2inch Bulb size. ( Come's in Black Gelcoat and is rounded like an original headlight, Made to be painted not stickered) Price=120.00 Shipping and Handling Price $30.00 = $150.00



2 Large Dummy Headlights 8inch Bulb size. ( Come's in Black Gelcoat and is rounded like an original headlight, Made to be painted not stickered) Price=110.00 Shipping and Handling Price $30.00 = $140.00





VFN Headlight decals are of the highest quality available and are made with a reflective tint to resemble a real light, they also are made on a weather resistant material . The cost of the decals are 45.00 for the set of small headlights and 60.00 for the pair of the large, these items are kept in stock for immediate shipment, You may also print a picture of these decals if you'd like to, free of charge.



38" Fiberglass Wheel Tubbs. Price=325.00 a pair Weight=10 a pair. Ship: Truck Freight .

44" Fiberglass Wheel Tubbs. Price=350.00 a pair Weight=12 a pair. Ship:Truck Freight.

NACA Ducts. Price=70.00 a pair Weight=1lb a pair. Ship: UPS Item.




T-Shirts sizes available:

T-Shirt Small Price=16.00 + Ship: UPS

T-Shirt Medium Price=16.00 + Ship: UPS

T-Shirt Large Price=16.00 + Ship: UPS

T-Shirt XLarge Price=16.00 + Ship: UPS

T-Shirt XXLarge Price=18.00 + Ship: UPS

T-Shirt XXXLarge Price=18.00 + Ship: UPS






How to Install an Ls1 / L-t1 Hood Instructional Video




How to Install a Fiberglass Dash Instructional Video




How to Install Fiberglass Doors Instructional Video



WSQ Mounting Instructions
